SPECS
| LOAD CAPACITY |
80,000 LBS |
| ENGINE HP |
85 |
| TRAVEL SPEED |
0-180'/MIN |
| GRADE CAPABILITY |
5% |
| WIDTH OVERALL |
21' 9" |
| WHEEL BASE |
17' |
| CLEAR WIDTH |
16' 6" |
| HEIGHT OVERALL |
20' |
| CLEAR HEIGHT |
18' |
Optional Equipment
- Night work package
- Hydraulic sling positioners (includes digital load guages)
- Custom colour choice – 189 colors to choose from
- Cold weather package – includes engine and hydraulic heater
- Radio Remote Control – Full drive / steering / throttle / slings
- Delivery, set-up, and operator training
FEATURES
- Cable Drop (into well) 8′
- Open end HSS frame, with forward mounted crossbeam & equalizing joint to relieve stress
- Fuel and hydraulic tanks are integral in main frame construction
- Power Unit: 85 HP CAT Diesel
- Drive System: Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
- Travel Speed: Variable from 0 to 100′ per minute
- Movement alarm when parking brake de-activated
- Grade Capability: Maximum 5% incline
- Lift Speed: From 1′ to 10′ per minute
- Steering: 90 degree steering capability
- Pilot operated safety lock-valves on each lift poin
- Gondola style with controls for all functions, including full engine instrumentation
- Four point lift functions can be simultaneously or independently operated
- 2 center-disconnect slings on lift beam
- Hydraulic load guages fore and aft weights
- Tires: 46″ x 16″ 28 ply lug tread industrial tires
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 2 year warranty on frame / 1 year on hydraulic components / or 2000 hrs whichever comes first
