SPECS
| LOAD CAPACITY |
20,000 LBS |
| BOAT LENGTH |
18' - 37' |
| TRAVEL SPEED |
0 - 9 MPH |
| GRADE CAPABILITY |
10% |
| A |
102" - 132" |
| B |
68" - 96" |
| C |
22" - 54" |
| D |
6' 4" |
| E |
19' 2" |
| F |
36' 6" |
Optional Equipment
- Custom colour choice – 189 colors to choose from
- Wireless remote control
- “L” cradle arms for more efficient cradle moving – Set of 4
- Stainless steel hose ends & fittings package
- Hot dip galvanized frame and hubs
- Hydraulic 4-arm package for handling non-cradled sail boats
FEATURES
- Powerboats to 37′ LOA
- Cradled sailboats to 38′ LOA
- Capacity (weight) – 20,000 lbs
- 10″ x 10″ x .250″ HSS steel tube frame
- Integral hydraulic front-end power unit
- Power: 24 HP Honda
- 90 degree steering
- Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
- Variable speed to 7 MPH
- Single lever joy-stick control
- Full engine instrumentation
- Hydraulic expanding width frame (expands from 68″ to 98″ inside)
- Hydraulic lift – wheel and tongue lift with frame heights to 54″
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated rear keel support strap
- 4 adjustable powerboat pads; 2 telescopic cradle bars with fixtures
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware (nuts/bolts/pins)
- Walking beam suspension
- Tires: Front – 10 – 16.5 Wearmaster / Rear – 9.00 x 14.5 bias ply
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
