SPECS
| LOAD CAPACITY |
50,000 lbs |
| BOAT LENGTH |
20' - 48' |
| TRAVEL SPEED |
0 - 9 MPH |
| GRADE CAPABILITY |
8% |
| A |
111" - 141" |
| B |
70" - 98" |
| C |
24" - 56" |
| D |
8' 6" |
| E |
27' |
| F |
46' 0" |
Optional Equipment
- Custom colour choice – 189 colors to choose from
- Wireless remote control
- L cradle arms for more efficient cradle moving – Set of 6
- Stainless steel hose ends & fittings package
- Hot dip galvanized frame and hubs
- Hydraulic 4-arm package for handling non-cradled sail boats
- Rear wheel drive assist
FEATURES
- Powerboats to 46′ LOA
- Cradled sailboats to 48′ LOA
- Capacity (weight) – 50,000 lbs
- 10″ x 10″ x .500″ HSS steel tube frame
- Integral hydraulic front-end power unit
- Power: 85 HP CAT Diesel
- 90 degree steering
- Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
- Variable speed to 9 MPH
- Single lever joy-stick control
- Full engine instrumentation
- Hydraulic expanding width frame (expands from 68″ to 98″ inside)
- Hydraulic lift – wheel and tongue lift with frame heights to 55″
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated rear keel support strap
- 10 adjustable powerboat pads; 3 telescopic cradle bars with fixtures
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware package (nuts/bolts/pins)
- Walking beam suspension
- Tires: Front – 31″ diameter lug-style drive tires / Rear – 28″ premium wide-trac solid Titan tires
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
