SPECS
| LOAD CAPACITY |
120,000 LBS |
| BOAT LENGTH |
30' - 70' |
| TRAVEL SPEED |
0 - 6 MPH |
| GRADE CAPABILITY |
6% |
| A |
156" - 186" |
| B |
96" - 126" |
| C |
30" - 66" |
| D |
16' 0" |
| E |
32' 6" |
| F |
61' 0" |
Optional Equipment
- Custom colour choice – 189 colors to choose from
- Wireless remote control
- Stainless steel hose ends & fittings package
- Hot dip galvanized frame and hubs
- Hydraulic arm package for handling non-cradled sail boats – 6 Arm Package
- Rear wheel drive assist
FEATURES
- 14″ x 14″ x .500″ HSS steel tube frame
- Integral hydraulic front-end power unit
- Power: 85 HP CAT Diesel
- 90 degree steering
- Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
- Variable speed to 6 MPH
- Single lever joy-stick control
- Full engine instrumentation
- Hydraulic expanding width frame (expands from 96″ to 126″ inside)
- Hydraulic lift – wheel and tongue lift with frame heights to 66″
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated fore and aft keel support strap
- Rear 4-pad equalizing rocker system
- 12 adjustable powerboat pads; 3 telescopic cradle bars with fixtures
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware (nut/bolts/pins)
- Walking beam suspension
- Tires: Front – 315/80-22.5″ 20 ply drive tires / Rear – 28″ premium wide-trac solid Titan tires
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
