SPECS
| Load Capacity |
40,000 lbs |
| Boat Length |
20' - 46' |
| A |
107" - 137" |
| B |
68" - 98" |
| C |
24" - 56" |
| D |
8' 6" |
| E |
24' |
| F |
38' 6" |
| Engine HP |
5.5 |
| Shipping Weight |
8,000 lbs |
Optional Equipment
- Custom PPG colour choice – 189 colors to choose from
- Black or white company decal (company name & telephone number) on both sides of unit
- “L” cradle arms for more efficient cradle moving – Set of 8
- Rear 4-pad equalizing rocker system
- Stainless steel hose ends & fittings package
- Wireless remote control
- Electric/hydraulic brake package – drum brakes
- Suspension package (includes fenders and lights)
- Hot dip galvanized frame and components (in lieu of standard painting process)
- Hydraulic 4-arm package with rear arm swivel for handling non-cradled sail boats
FEATURES
- Powerboats to 46′ LOA
- Cradled sailboats to 48′ LOA
- Capacity (weight) – 40,000 lbs off-road
- 10″ x 10″ x .500″ HSS steel tube frame
- Hydraulic expanding width frame (expands from 68″ to 98″inside)
- Hydraulic tongue with pintle ring
- Hydraulic lift – wheel and tongue lift with frame heights to 55″
- Hydraulic Power: 6.5 HP Honda gasoline engine
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated rear keel support strap
- 8 adjustable powerboat pads, 3 telescopic cradle bars with fixtures
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware (nuts/bolts/pins)
- Walking beam suspension
- Tires: 28″ premium wide-trac solid Titan tires
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
