YH-12Highway Trailer

SPECS

Yard Trailer specs

Custom PPG colour choice – 189 colors to choose from
Black or white decal (company name & telephone number) on both sides of unit
Electric start
“L” cradle arms for more efficient cradle moving Set of 8
Hydraulic fifth wheel gooseneck (2″ SAE pin or Inverted Binkley)
Air-ride suspension system with 12 volt compressor and tank
Air/hydraulic brakes with required anti-lock braking system
Stainless steel hose ends & fittings package (includes stainless steel cylinder shafts)
Wireless remote control
Hot dip galvanized frame and components (in lieu of standard painting process)
HD Package – consists of:
- Heavier frame
- Double open gooseneck – 2″ SAE
- 2′ longer frame
Hydraulic 4-arm package with rear swivel for handling non-cradled sail boats

10″ x 10″ x .375″ HSS steel tube frame
Hydraulic expanding width frame (expands from 61″ – 98″ inside)
Hydraulic tongue with pintle ring
Hydraulic lift – wheel and tongue lift with frame heights to 58″
Hydraulic Power: 6.5 HP Honda gasoline engine
Pilot operated safety lock-valves on main frame lift
Hydraulically operated rear keel support strap
8 adjustable powerboat pads; 3 telescopic cradle bars with fixtures
O-ring boss and JIC hydraulic fittings
Zinc coated steel hose ends and fittings
High strength hydraulic cylinder shafts
Stainless steel hardware (nuts/bolts/pins)
Nitrogen ride suspension
MTO/DOT approved lighting package
LED lights with marine grade wiring
Rubber fenders
Aluminum rims
Electric / hydraulic actuated disc brakes
Kodiak 12K silver cadmium plated disc brakes
Tires: 245/70R17.5 radials (includes spare and carrier)
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
