YH-9

Highway Trailer

SPECS

ON ROAD 18,000 lbs
OFF ROAD 24,000 lbs
BOAT LENGTH 18' - 37'
A 102" - 132"
B 61" - 98"
C 24" - 56"
D 6'
E 20' 6"
F 32' 10"
Shipping Weight 8,000 lbs

Yard Trailer specs

Optional Equipment

  • Custom PPG colour choice – 189 colors to choose from
  • Black or white decal (company name & telephone number) on both sides of unit
  • Electric start
  • “L” cradle arms for more efficient cradle moving  Set of 6
  • Hydraulic fifth wheel gooseneck (2″ SAE pin or Inverted Binkley)
  • Air-ride suspension system with 12 volt compressor and tank
  • Stainless steel hose ends & fittings package (includes stainless steel cylinder shafts)
  • Wireless remote control
  • Hot dip galvanized frame and components (in lieu of standard painting process)
  • Hydraulic 4-arm package with rear swivel for handling non-cradled sail boats

FEATURES

  • 10″ x 10″ x .250″ HSS steel tube frame
  • Hydraulic expanding width frame  (expands from 61″ – 98″ inside)
  • Hydraulic tongue with pintle ring
  • Hydraulic lift – wheel and tongue lift with frame heights to 58″
  • Hydraulic Power: 6.5 HP Honda gasoline engine
  • Pilot operated safety lock-valves on main frame lift
  • Hydraulically operated rear keel support strap
  • 6 adjustable powerboat pads; 3 telescopic cradle bars with fixtures
  • O-ring boss and JIC hydraulic fittings
  • Zinc coated steel hose ends and fittings
  • High strength hydraulic cylinder shafts
  • Stainless steel hardware (nuts/bolts/pins)
  • Nitrogen ride suspension
  • MTO/DOT approved lighting package
  • LED lights with marine grade wiring
  • Rubber fenders
  • Aluminum rims
  • Electric / hydraulic actuated disc brakes
  • Kodiak 10K silver cadmium plated disc brakes
  • Tires:   245/70R17.5 radials  (includes spare and carrier)
  • Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
  • Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
  • 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
