YH-18

Highway Trailer

SPECS

ON ROAD 36,000 lbs
OFF ROAD 36,000 lbs
BOAT LENGTH 28' - 50'
A 102" - 155"
B 52" - 107"
C 25" - 62"
D 7' 6"
E 36'
F 45' 1"
Shipping Weight 12,500 lbs

Yard Trailer specs

Optional Equipment

  • Custom colour choice – 189 colors to choose from
  • Black or white decal (company name and telephone number) on both sides of unit
  • Wireless remote control
  • Hot dip galvanized frame and hubs
  • Hydraulic 4-arm package for handling non-cradled sail boats

FEATURES

  • 10″ x 10″ x .500″ HSS steel tube frame
  • Hydraulic open center HD gooseneck (for semi-tractor)
  • Hydraulic expanding width frame (expands from 52″ – 107″ inside)
  • Hydraulic lift – wheel and tongue lift with frame heights to 58″
  • Hydraulic Power: 6.5 HP Honda gasoline engine
  • Pilot operated safety lock-valves on main frame lift
  • Hydraulically operated rear keel support strap
  • 10¬†adjustable powerboat pads
  • O-ring boss and JIC hydraulic fittings
  • Zinc coated steel hose ends and fittings
  • High strength hydraulic cylinder shafts
  • Stainless steel hardware (nuts/bolts/pins)
  • MTO/DOT approved lighting package
  • LED lights with marine grade wiring
  • Rubber fenders
  • Air/hydraulic actuated brakes with ABS
  • 12,000 lbs axles with Kodiak disc brakes
  • Air-ride suspension
  • On-board 12V air compressor
  • Tires: 245/70R17.5 radials (includes spare and carrier)
  • Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
  • Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
  • 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
