YH-15Highway Trailer
SPECS
ON ROAD | 30,000 lbs |
---|---|
OFF ROAD | 50,000 lbs |
BOAT LENGTH | 20' - 50' |
A | 102" - 155" |
B | 41" - 94" |
C | 26" - 64" |
D | 6' 6" |
E | 31' 3" |
F | 48' 0" |
Shipping Weight | 14,500 lbs |
Optional Equipment
- Custom PPG colour choice – 189 colors to choose from
- Black or white decal (company name & telephone number) on both sides of unit
- Electric start
- Air-ride suspension
- Rear strobes (amber LED)
- Additional hydraulic winch strap – mounted forward
- Aluminum toolbox
- Stainless steel hose ends & fittings package (includes stainless steel cylinder shafts)
- Wireless remote control
- Hot dip galvanized frame and components (in lieu of standard painting process)
- Hydraulic 6-arm package for handling non-cradled sail boats
FEATURES
- 12″ x 12″ x .500″ HSS steel tube frame
- Hydraulic expanding width frame (expands from 41″ – 94″ inside)
- Hydraulic HD double open low-profile gooseneck (for semi-tractor)
- Hydraulic lift – wheel and tongue lift with frame heights to 58″
- Hydraulic Power: 6.5 HP Honda gasoline engine
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated keel support strap
- 10 adjustable powerboat pads; 3 HD telescopic cradle bars with fixtures
- O-ring boss and JIC hydraulic fittings
- Rear 4-pad equalizing rockers
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware (nuts/bolts/pins)
- Nitrogen ride suspension
- MTO/DOT approved lighting package (includes center frame-mounted turn signals)
- LED lights with marine grade wiring
- Extendable rear tail lights
- Power outlet at rear of trailer for additional marker/strobe lights
- Air / hydraulic braking system with anti-lock (as required by MTO/DOT)
- DEXTER 15K axles with 12 1/4 x 5 brakes with riveted shoes
- Tires: 245/70R17.5 – – 9 rims & tires total (including spare and dual wheels)
- Aluminum Rims
- Storage mount for spare tire
- Flexible rubber fenders
- Fore and aft flag holders
-
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
-
Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
