SPECS
| ON ROAD |
8,000 lbs |
| OFF ROAD |
10,000 lbs |
| BOAT LENGTH |
16' - 28' |
| A |
98" |
| B |
64" |
| C |
20" - 40" |
| D |
5' |
| E |
16' 3" |
| F |
26' 0" |
| Shipping Weight |
4,100 lbs |
Optional Equipment
- Custom PPG colour choice – 189 colors to choose from
- Black or white decal (company name & telephone number) on both sides of unit
- Electric / hydraulic disc brakes – silver cadmium
- Air-ride suspension system with 12 volt compressor and tank
- Stainless steel hose ends & fittings package (includes stainless steel cylinder shafts)
- Wireless remote control
- Hot dip galvanized frame and components (in lieu of standard painting process)
- Hydraulic 4-arm package for handling non-cradled sail boats
FEATURES
- 8″ x 8″ x .250″ HSS steel tube frame
- Fixed width frame (non-expanding) with 64″ clear inside width
- Hydraulic tongue with pintle ring
- Hydraulic lift – wheel and tongue lift with frame heights to 40″
- Hydraulic Power: 5.5 HP Honda gasoline engine
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated rear keel support strap
- 4 adjustable powerboat pads
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
- High strength hydraulic cylinder shafts
- Stainless steel hardware (nuts/bolts/pins)
- Nitrogen ride suspension
- MTO/DOT approved lighting package
- LED lights with marine grade wiring
- Electric brakes and rubber fenders
- Tires: 235/80R-16 (includes spare tire and carrier)
- Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
- Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
- 3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
