YH-60
Highway Trailer
SPECS
| ON ROAD | 120,000 lbs |
|---|---|
| OFF ROAD | 120,000 lbs |
| BOAT LENGTH | 30' - 75' |
| A | 144" - 191" |
| B | 63" - 110" |
| C | 33" - 60" |
| D | 16' 4" |
| E | 44' 5" |
| F | 78' |
| Shipping Weight | 34,300 lbs |
Optional Equipment
- Custom PPG colour choice – 189 colors to choose from
- Black or white decal (company name and telephone number) on both sides of unit
- Wireless remote control
- Hot dip galvanized frame and hubs
FEATURES
- 16″ x 16″ x .500″ HSS steel tube frame
- Hydraulic expanding width frame (expands from 63″ – 110″ clear inside width)
- Double hydraulic low-profile gooseneck
- Hydraulic lift – wheel and tongue lift with frame heights to approximately 60″
- Hydraulic Power: 20 HP Honda gasoline engine with electric start
- Pilot operated safety lock-valves on main frame lift
- Hydraulically operated fore and aft keel support straps
- Removable (hinged) forward frame expansion and alignment bar
- Forward frame features outside pockets for extra pad locations
- Rear 4-pad equalizing rockers
- Mid-frame hydraulically adjustable 4-pad equalizing rockers
- 16 adjustable powerboat pads
- O-ring boss and JIC hydraulic fittings
- Zinc coated steel hose ends and fittings
-
High strength hydraulic cylinder shafts
-
Stainless steel hardware (nuts/bolts/pins)
- Nitrogen ride suspension system
- MTO/DOT approved lighting package (includes built-in rear strobe lights)
- LED lights with marine grade wiring
- Extendable rear tail lights and mid-frame mounted turn signals
- Power outlet at rear of trailer for additional marker/strobe lights
- Air / hydraulic braking system with anti-lock (as required by MTO/DOT)
- Tires: 235/70R17.5 radials – – 28 rims & tires total (includes 4 spares)
- Rubber fenders
-
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
-
Polyurethane paint – 2 coats of Conolift Red PPG commercial performance paint
-
3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
