YH-3
Highway Trailer
SPECS
| ON ROAD | 6,000 lbs |
|---|---|
| OFF ROAD | 8,000 lbs |
| BOAT LENGTH | 16' - 26' |
| A | 89" |
| B | 55" |
| C | 18" |
| D | 4' 6" |
| E | 13' 6" |
| F | 22' 9" |
| Shipping Weight | 3,200 lbs |
Optional Equipment
- Custom Colour choice – 189 colors to choose from
- Black or white decal (company name & telephone number) on both sides of unit
- Electric / hydraulic brakes
- Air-ride suspension system with 12 volt compressor and tank
- Hydraulically operated rear keel support strap
- Stainless steel hose ends & fittings package (includes SS cylinder shafts)
- Wireless remote control 3 Functions
- Hot dip galvanized frame and hubs (in lieu of standard painting process)
FEATURES
- 7″ x 7″ x .188″ HSS steel tube
- Fixed width frame (non-expanding) with 55″ clear inside width
- Hydraulic tongue with pintle ring
- Hydraulic lift – wheel and tongue lift with frame heights to 48″
-
Hydraulic Power: 5.5 HP Honda gasoline engine
-
Pilot operated safety lock-valves on main frame lift
-
Manually operated rear keel support strap
-
4 adjustable powerboat pads
-
O-ring boss and JIC hydraulic fittings
-
Zinc coated steel hose ends and fittings
-
High strength hydraulic cylinder shafts
-
Stainless steel hardware (nuts/bolts/pins)
-
Nitrogen ride suspension
-
MTO/DOT approved lighting package
-
LED lights with marine grade wiring
-
Electric brakes with breakaway switch
-
Tires: 225/75R15 radials (includes spare tire and carrier)
-
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
-
Polyurethane paint – 2 coats of Conolift Red PPG commecial performance paint
-
3 year warranty on frame, 2 years on hydraulic components with 90 days limited warranty on running gear
